Amortiguador

Fox Float X2 Factory Kashima 205x65mm. 2-positions lever compression (Open/Firm), low-speed compression, low-speed rebound, air preload. Trunnion top mount, 30x8mm bottom bushings.

---

Ajuste del amortiguador

CS 30 compression, 1.1 Bleed, RS40 rebound, Rezi B40, LML, Long MCU, 0 volume spacers.

---

Horquilla

Fox Podium 29 Float GRIP X2 Factory Kashima, 170mm, tapered steerer tube, Boost 20x110mm thru axle, 44mm offset. High and low-speed compression, high and low-speed rebound, air preload.

---

Dirección

Acros custom ZS56/ZS56, 1-1/8", 1.5" head tube, internal cable routing, sealing plugs, without blocklock.

---

Potencia

Onoff S9 30mm 0º, Full CNC, 31.8mm barbore.

---

Manillar

Onoff S9 1.0 Carbon, rise: 25mm, width: 800mm, 8º backsweep, 5º upsweep, 31.8mm barbore. L and XL sizes: 38mm rise.

---

Puños

Onoff Desert Pro, CNC lock-on, 135mm. L and XL: thicker size.

---

Tija

RockShox Reverb AXS, diameter 31.6mm, w/AXS Pod Controller Rocker Paddle. S size: 398.2x125mm, M size: 448.2x150mm, ML size: 498.2x175mm, L size: 548.2x200mm, XL size: 548.2x200mm.

---

Sillín

Ergon SM10 E-Mountain Black.

---

Freno delantero

Sram Maven Ultimate, 18 millimeter 4-piston caliper, HS2 220mm IS 6 bolts one-piece rotor, steel-backed metal sintered pads.

---

Freno trasero

Sram Maven Ultimate, 18 millimeter 4-piston caliper, HS2 200mm IS 6 bolts one-piece rotor, steel-backed metal sintered pads.

---

Manetas de freno

Sram Maven Ultimate, carbon lever, SwingLink and lever pivot bearings, tools-free reach adjust.

---

Llantas

DT Swiss Hybrid HXC 1500 Spline, Carbon, 30mm internal width, tubeless ready, 28 spokes.

---

Radios

DT Swiss Straightpull spokes, DT Hybrid II, black.

---

Buje delantero

DT Swiss 350, 20x110mm Boost, Disc IS (6-bolt).

---

Buje trasero

DT Swiss 240 Classic with 72T Ratchet DEG System, Boost 12x148mm, IS 6 bolts, XD freehub.

---

Neumático delantero

Maxxis Assegai 29x2.5WT, tubeless ready, 3C MaxxGrip compound, DD protection, 120x2TPI, folding bead.

---

Neumático trasero

Maxxis Minion DHR II 27.5x2.5WT, tubeless ready, 3C MaxxTerra compound, DD protection, 120x2TPI, folding bead.

---

Bielas

e*thirteen Helix Race Carbon e*spec. All sizes: 155mm.

---

Platos

Sram Eagle 36T T-Type, 104BCD, steel, CL55.

---

Cadena

Sram GX Eagle T-Type, 12s Flattop, w/PowerLock.

---

Cambio - trasero

Sram X0 Eagle AXS T-Type, 12s.

---

Mandos - pulsadores de cambio

Sram Eagle AXS Pod Controller Rocker Paddle w/discrete clamp, 12s.

---

Piñones

Sram XS 1275, 10-52T, T-Type, 12s.

---

Otros

Sram AXS Extension Cord / Avinox 12A Charger.

---

Peso sin pedales

23.1 kg

---

Display

Avinox DP100 Display / Avinox BC100 Wireless Controller (L&R).

---

Motor

Avinox M2S

---

Batería

Avinox 800Wh Battery
